3M DBI-SALA Fall Protection 7100207472 Permanent Cable Guide, For Use With Lad-Saf™ 199 ft Fixed Ladder System

The Lad-Saf™ flexible cable system consists of a top and bottom bracket that act as anchors for a steel cable that runs the length of the climbing area. A Lad-Saf™ sleeve connects the worker to the system, automatically follows the user during the climb and locks onto the cable in the event of a fall, allowing the user to regain their footing. Designed for easy-of-use, economy and versatility, optional brackets/designs are available for bolting or welding the system, choose rung clamp sizes/styles, choose systems for straight or curved ladders and for connection to wood, concrete or steel structures. Hundreds of different brackets, styles and configurations are available to suit almost any application. In addition, the versatile system can be used by up to four workers simultaneously for added jobsite flexibility.

3M DBI-SALA Fall Protection, 7100207472, Cable Guide, Permanent, For Use With: Lad-Saf™ 199 ft Fixed Ladder System, Specifications: 310 lb Capacity, Steel, Galvanized, 6.9 in L x 1.5 in W x 1.2 in H Dimensions

• Bypassable intermediate Cable Guide for Lad-Saf™ system
• Bolts to ladder rung (1 guide required for every 8 m)
• Fits rungs up to 1-1/8 in diameter
• Extremely rugged and corrosion-resistant galvanized mounting hardware
• Non-metallic guide prevents metal-to-metal contact
• Fast, easy and safe installation
• Order top and bottom brackets, cable and sleeve separately

• Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3MDBISALAFallProtection_5901980_Technical_Bulletin.pdf
• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3MDBISALAFallProtection_6100400_Manual.pdf
• VIDEO LINK https://multimedia.3m.com/mws/media/1281109O/3m-dbi-sala-lad-saf-flexible-cable-ladder-safety-systems.mp4&fn=3m_psd_fp_2104_lad_saf_video_2019_update_global_master_final_2_1920x1080_R1.mp4
