3M™ 7000133177 QI Series Cold Shrink Insulator, 0.4 in Dia Min, 1.45 in Max Diameter, 4-1/4 in L, 1400 psi Tensile Strength, EPDM

The 3M™ QI cold shrink quick insulator is great on in-line conductor transition connectors, as well asset screw or oversized connectors. This insulator holds up to the test over extended periods of time and exposure. It offers a tight seal and good thermal stability in storage and shipping conditions and can withstand temperatures ranging from -40 to 194 deg f (-40 to 90 deg C). Our QI insulator works great on low-voltage, single-conductor, insulated cables. This product is rohs 2011/65/EU compliant and ANSI Certified.

3M™, 7000133177, Insulator, Cold Shrink, Series: QI Series, 0.4 in Diameter Minimum, 1.45 in Diameter Maximum, 4-1/4 in Length, 1400 psi Tensile Strength, Elongation: 7.5, 365 V/mil Dielectric Strength, EPDM, Black

• Low voltage single-conductor insulated cable
• 1 kV voltage rating
• Simple hand installation, no tools required
• No heat source, heat guns or torches required
• Accommodates wide-range of cable sizes, including street lighting
• Good thermal stability during storage and shipping
• Seals tight, retains resiliency and pressure, even after years of aging and exposure
• Water-resistant
• 2 awg to 750 kcmil (cu), 2 awg to 500 kcmil (al) conductor size
• Specially designed for primary insulation of solid dielectric insulated wires and cable splicing rated to 1000 v
• Offers excellent wet electrical properties and resists water, acids and alkalis
• Withstands temperatures of -40 to 194 deg f (-40 to 90 deg c)
• Environmental sealing for communication and other non-electrical applications
• Made of EPDM rubber which contains no chlorides or sulfur
• Open-ended tubular sleeves with a sealing mastic on each end

• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_01c305d05f21bbd8a6fdb530b868c9e240305729a954edb74dbb853f58a3e80d.pdf
• Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_a95770bd4115fd1662cb5adcae40ad27b271cf4c4f63052de15567bc9094ac68.pdf
• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b720029de8bfe2e74346a4cc586fca04045c2b8498c4738d411ed5636798c2cf.pdf
• SDS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_cdce700beca3fddcee25c96adef9be8aa39bd7c8cb3356f870de863190a8d4f6.pdf
