3M™ 7000031603 8430 Cold Shrink Insulator, 93.7 mm Dia Min, 426 mm Max Diameter, 1400 psi Tensile Strength, EPDM Rubber Insulation

Rely on the 3M™ 8430 cold shrink connector insulator to insulate all solid dielectric-insulated wires and cable splices, including secondary splices. The moisture tight sealing of this insulator makes it ideal for use underground in direct buried or submersible dig-in repairs, as it's designed to maintain pressure and resiliency under these conditions. This cold shrink insulator is ANSI certified and RoHS 2011/65/EU compliant and provides reliable physical protection of high-voltage, air insulated lugs and connectors. It comes in a diameter range of 1.68 to 3.69 in, and provides environmental sealing for nonelectrical applications such as communication lines.

CASE OF 10 3M 7000031603 COLD SHRINK INSULATOR 8430-18 1250-2000 KCMIL

• Copper conductor with polyolefin foam
• Provides flexible, moisture tight seal
• Unishield®, wire shield, tape shield cable
• 18 in relaxed tube length, 14 in max connector length
• One conductor, 1750 kcmil, 1500 kcmil, 2000 kcmil, 1250 kcmil conductor sizes
• Simple installation which requires no tools
• Sealing of terminal lug barrels, conduit couplings and conduit-to-cable breakouts
• Withstands temperatures of -40 to 194 deg f (-40 to 90 deg c)
• Withstands temperatures of -40 to 194 deg f (-40 to 90 deg c)
• Environmental sealing for communication and other non-electrical applications
• Made of EPDM rubber which contains no chlorides or sulfur
• Covers a wide range of cable cross sections

• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_4301d1108b84b90addcc0b7056741e277aa2097d85a256107a11dcbe8c6214dc.pdf
• SDS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_dbcdd296a8e947aabc80cbb392c2b75076b34dbf903c357500b17c71cf1d20fb.pdf
